V-Series Single Auger Grain Carts

The Brent V-Series single auger grain carts bring operator visibility and convenience to new limits.  The exclusive forward-reaching auger design provides industry-leading reach which maximizes visibility of the auger and downspout during unloading.  This reduces operator fatigue and minimizes the risk of spilling to keep your harvest running smoothly.  Choose from models V1500, V1300, V1100, V1000, V800 and V700 with capacities ranging from 1,500 to 750 bushels and unloading speeds up to 600 bushels per minute depending on model.

When you're ready for the best, choose the leader and innovator in grain handling equipment....choose a Brent V-Series grain cart.



    Auger

    Standard Features

    Operator Visibility Maximized!

    • Exclusive, forward-reaching corner auger with a side-folding design increases the upper auger length for industry-leading auger reach and height
      • This innovative single-auger design allows the operator to easily view the auger and downspout from the side window of the tractor cab, reducing fatigue and minimizing the risk of spilling
    • Unloading accuracy is optimized when the downspout is pointed straight down and the V-Series provides up to 10 feet of auger side reach when in this position which reduces the risk of throwing grain off target
    • On models V1500, V1300 and V1100 the auger folds within the length of the tank for a compact design

    High-Speed Unloading

    • Models V1500, V1300 and V1100 feature a patent-pending auger design with a U-Joint transition for increased side reach
    • Models V1500, V1300 and V1100 feature a 20" diameter auger for unloading speeds up to 600 bushels per minute
    • Models V1000 and V800 feature a 20" and model V700 features an 18" diameter auger for unloading speeds up to 550 and 500 bushels per minute
    • Exclusive design with a recessed auger sump funnels grain down into the unloading auger for the quickest and gentlest grain handling
    • Exclusively designed 3/8” thick max-edge auger flighting features 1/4” thick Abrasion Resistant (AR400) strips added in high volume areas to extend the flighting life for long-term, trouble-free use.
      • AR400 material is a high-carbon alloy steel that is harder and increases the durability of the steel.
      • Electronic balancing of the upper and lower auger flightings provides smooth operation at all speeds.
      • Two-point auger engagement between the upper and lower vertical auger sections ensures a smooth transition of grain and reduces shock during startup.
      • Patented soft-start auger connection cushions the upper and lower vertical augers from harsh tractor PTO engagements which reduces stress and extends the driveline life.

    4-Way Downspout

    • 4-Way directional downspout provides 4 feet of in-and-out and 5 feet of side-to-side control with minimal change in the discharge height for easily topping off trucks with limited tractor movement
      • 10 feet of auger side reach with the downspout pointed straight down minimizes the chance of throwing grain off target while unloading
    • The hydraulically driven gear motor on the downspout provides a smooth and responsive feel when adjusting from side-to-side

    Convenience

    • Dual spout-mounted LED unloading lights on models V1500, V1300, V1100, V1000 and V800 and a single spout-mounted LED unloading light on model V700 for easy night time operation
    • The cushioned auger fold cylinder gently folds and unfolds the upper auger into the loading and transport position
      • When unfolded, the hydraulic locking mechanism holds the upper and lower augers tightly together for a leak-free seal

    Tank

    Standard Features

    Capacities & Design

    • Models V1500, V1300, V1100, V1000, V800 and V700 feature tank capacities of 1,500, 1,300, 1,100, 1,000, 850 and 750 bushels
    • Industry-leading front and rear tank slopes in a single auger design and graphite-coated interior ensure complete cleanout and faster unloading speeds regardless of grain moisture
    • Hydraulically operated 36" flow gate features a highly visible position indicator for easily controlling grain flow while unloading

    Construction

    • Exclusive manufacturing process crimps side panels for added strength and exposed seams are silicone sealed for corrosion resistance
    • Durable, high-grade enamel paint is baked on in tractor red or green for a long-lasting and smooth, automotive-like finish
    • Conveniently located wheel-operated gravity unloading door located on the auger sump permits easy cleanout
    • Interior LED hopper work light for easy night time operation
    • Models V1500, V1300 and V1100 features a standard weatherguard roll-over tarp to protect your harvested crop
      • Optional on models V1000, V800 and V700
    • Front viewing ladder and front and rear shatterproof windows allow you to easily monitor tank contents
    • Standard transport chain, D.O.T. approved flashing LED taillights, side marker lights, reflective markings and SMV emblem for safer road transport

    Undercarriage

    Standard Features

    Construction

    • Models V1500 and V1300 features a track axle with traditional or Equalizer track system or a rigid axle with high-flotation single wheels and tires
    • Models V1100 and V1000 feature your choice of a track axle, 134" rigid axle or an adjustable axle with single wheels and tires that can be widened from 134" to 150" centers
    • Models V800 and V700 feature your choice of a 120" rigid axle with single wheels or an adjustable axle with single or straddle dual wheels that can be widened from 120" to 150" centers
    • Cast 2" single-tang hitch features a smooth chamfer opening and bushings that fit numerous hitch pin sizes which allows the cart to trail smoothly
    • Single wheel and tire axles on model V1300 feature 12-bolt hubs with gusseted reinforcements and 6" special alloy, high-tensile spindles
    • Single wheel and tire axles on models V1100, V1000, V800 and V700 feature 10-bolt hubs with gusseted reinforcements and 4 1/2" special alloy, high-tensile spindles
    • Exclusively designed, heavy-duty 45° gearbox features a 1 3/4" output shaft for trouble-free operation
    • Heavy-wall tubular steel main frame and axle, 12-gauge steel shell and 8-gauge steel underframe
    • Heavy-duty side-wind jack is easy to operate for convenient tractor hookup

    High-Flotation Singles

    • All models are available with a high-flotation single wheel and tire with a variety of tire sizes available depending on model.
      • All models can be equipped with a rigid axle and models V1100, V1000, V800 and V700 can be equipped with an adjustable axle to meet individual grower preferences.
      • Models V1500 and V1300 feature 12-bolt hubs and models V1100, V1000, V800 and V700 are equipped with 10-bolt hubs and every hub is manufactured from special alloy, high-strength steel with gusseted reinforcements for trouble-free operation.

    Equalizer™ Track Systems

    • 42" wide track belt provides the widest footprint in the industry!
    • Patented design features 8° of side-to-side camber and 20° of front-to-back pivot with independent movement of each track to provide uniform ground contact on uneven terrain for optimum flotation
    • Available on models V1500 and V1300:
      • 42" wide rubber track with 105" of ground contact length provides the largest footprint in the industry, over 60 square feet!
      • Four cast, pivoting mid-rollers are on the same plane as the main end-wheels for optimum flotation
    • Available on models V1300 and V1100:
      • 42" wide rubber track with 87" of ground contact length provides a footprint of over 50 square feet!
      • Two cast, pivoting mid-rollers are on the same plane as the main end-wheels for optimum flotation
    • Shallow tread belt design for greater flotation and traction
    • 40" main end-wheels feature 10-bolt hubs for added durability
    • All end-wheels and mid-rollers feature hubs that are greaseable and triple-lip seals with a steel guard for optimum lubrication
    • Hydraulic belt tensioning adjustment for easier track alignment, optimum ground contact and even weight distribution
    • Standard auto-greaser system for automatic application at more frequent intervals for consistent lubrication

    Traditional Track System

    • 36" wide track belt with 105” of ground contact length on the 4-bogie design available on models V1500, V1300 and V1100 and 87” of ground contact length on the 2-bogie design available on model V1100
    • 40" main end-wheels feature 10-bolt hubs that are greaseable with triple-lip seals and a steel guard for optimum lubrication.
      • Greaseable hubs ensure the operator can push out any dirt and debris from the hub, increasing life and eliminating down time.
    • Hydraulic belt tensioning adjustment for easier track alignment, optimum ground contact and even weight distribution.
      • Conveniently located PSI gauge allows the operator to easily check pressure, ensuring the proper tension is being applied to the belt.
    • Cast, pivoting mid-rollers are on the same plane as the main end-wheels for optimum flotation and reduced stress on the belt.
    • Exclusive rubber belt construction molds the tread, guide lugs and belt together as one piece, which increases durability and eliminates the need for glued on components.

    Economical Track System

    • Available on models V1100, V1000 and V800 with a 36" wide rubber track belt that is molded as 1 peice for the greatest strength and durability
    • 32" main end-wheels feature 8-bolt hubs for added durability
    • Two cast, pivoting mid-rollers are on the same plane as the main end-wheels for optimum flotation and give the track 75" of ground contact length
    • All end-wheels and mid-rollers feature hubs that are greaseable and triple-lip seals with a steel guard for optimum lubrication
    • Hydraulic belt tensioning adjustment for easier track alignment, optimum ground contact and even weight distribution

    UHarvest

    UHARVEST PRO GRAIN CART SCALE

    Your complete ISOBUS grain cart scale and harvest data solution!  By utilizing ISOBUS technology, the user can operate the UHarvest® Pro grain cart scale and data management system on the virtual terminal display in the tractor, eliminating the need for batteries and extra monitors in the cab.  Simply plug into the ISOBUS port and you’re ready to go!  With a free subscription to Slingshot® reporting, you have a complete data management solution that seamlessly integrates with most crop insurance requirements.  Need to send your data to the cloud?  Simply connect your mobile device with cellular data to the Bluetooth signal and open the free UHarvest Pro app to make it happen!

    Standard Features

    • The UHarvest Pro grain cart scale and data management system works on any ISOBUS Virtual Terminal display. The easy-to-use platform permits easy setup and operation directly from a monitor that you already have in the tractor cab.  No need for additional monitors, cabling or batteries!
    • The harvest data structure allows you to track each load using a grower, farm and field structure as well as truck, destination and crop variety for complete harvest data reporting.
    • Easily add up to 5 custom crop types along with the included crop types. Plus, with UHarvest Pro, you can setup truck and bin capacities to help monitor your harvest production and storage requirements.
    • Accu-Save automatically records loads using the proximity sensor mounted on the driveshaft of the grain cart for the most accurate and complete harvest record keeping possible.
    • Hitch weight management feature allows the operator to maintain optimum tractor and cart control by keeping the grain load evenly distributed.  This feature not only monitors grain and total cart weight, it also shows real-time hitch weight and a color gauge to avoid overloading the hitch during loading.
    • Use the Combine Verify screen to easily calibrate the combine yield monitor with one touch. This calibration event is saved in the UHarvest Pro system once the verification process is completed.
    • Slingshot cloud reporting is included with every purchase of the UHarvest Pro grain cart scale system.  Slingshot is a secure, first-of-its-kind, web-based system that lets you send, store and share your harvest data.  Using the free UHarvest Pro mobile app, you can easily send files from the field on a mobile device with cellular connection to your Slingshot account.
    • The free UHarvest Pro mobile app allows you to send your harvest data to Slingshot directly from the field.  Once you have connected your mobile device to the Bluetooth connection provided by the GCM, launch the app and you're ready to go.  Upload once a day or once a season. It's easy to use and completely up to you! (available on IOS and Android devices).

    Optional Features

    • The optional Accu-Load technology provides quick and easy loading of trucks by closing the grain cart’s flow gate when the desired weight is unloaded.  After you’ve installed the HCV (hydraulic control valve) on the cart, simply push the “Auto” button for precise weight unloading.  Each truck weight is matched to the truck name for easier operation.  The operator can then focus on topping off each truck and proper grain placement.
    • Want to easily send a report to your crop insurance agent that includes the actual dry bushel count? Consider it done with the optional Moisture Sense system. It measures grain moisture as it leaves the cart and averages the content of each load, then converts all grain unloaded to standard dry bushels for the ultimate in harvest record keeping.

    Visit uharvest.net for complete information pertaining to the UHarvest Pro grain cart scale and data management system.

    Accessories

    Scale Packages

    • ​UHarvest Data Management and UHarvest Lite scales systems.  Finally, a complete harvest data solution!
      • Please refer to the UHarvest tab or uharvest.net for more information
    • Model 520 Scale Package
      • Features auto-log and the patent-pending start/stop button for ease of use.
      • The large, mutli-line display features an alpha-numeric keyboard for easily editing or changing fields
      • Combine check button can help calibrate the the combine's yield monitor, accumulation of weights per field entry and the ability to store 1 year's worth of harvest data in the monitor's memory
      • Comes with PC software and a 1GB USB flash drive to easily download your harvest information to your computer in Excel or PDF format
    • Model 410 Scale Package
      • Scale display specifically designed for ease of use with the patent-pending start/stop button
      • Assign, view and change six character field information and accumulate weights within a field
      • Optional printer is required for record keeping
    • Remote scale display for the 520 and 410 scale indicators features a 4" x 18" LED screen that can be mounted to the side of the grain cart for easy viewing of the loaded weight of the grain cart

    Weatherguard Roll Tarp

    • Weatherguard rollover tarp is standard on the V1500, V1300 and V1100 and optional on the other models to protect the tank’s contents and features a custom-design for a sleek appearance and easy operation.
      • Low-profile tarp bows are reinforced to eliminate sagging and the heavy-duty, 18 oz. black canvas can withstand harsh weather conditions.
      • Semi-trailer locking design provides optimum protection from high winds and moisture.

    Hydraulic Drives

    • Tongue-mounted for easy installation - the grain cart can still be operated with a PTO if desired
    • Two hydraulic motor capacities depending on model:
      • 100 gallon per minute provides up to 375 bushel per minute unloading speeds and reuquires 3 sets of hydraulic ports
      • 55 gallon per minute provides up to 300 bushel per minute unloading speeds and requires 2 sets of hydraulic ports

    Color Camera

    • 7" color, 12V monitor which mounts in the tractor cab
    • Sideboard mounted, weather-proof camera to monitor the unloading auger
    • Optional second color camera views rear traffic during transport

    Auto-Greaser for Tracked Undercarriage

    • Reduce your daily maintenance on track undercarriages by automatically delivering small amounts of grease to each pivoting joint at more frequent intervals
    • Powered by an electric grease pump with a 2-liter grease reservoir and programmable grease intervals

    Specs

    Model Number V1500 V1300 V1100 V1000 V800 V700

    *Capacities measured with #2 corn at 15% moisture, 56# test weight.

    Due to continuing improvements in the design and manufacture of Unverferth products, all specifications contained herein are subject to change without notice.

    Capacity (bushels)* 1500 1300 1100 1000 850 750
    Minimum Tractor HP 300 250 225 200 180 150
    Loaded Tongue Weight (lbs) 7,850 7,300 6,031 5,863 5,243 4,840
    Empty Tongue Weight (lbs) 2,340 3,830 2,873 2,553 2,479 2,670
    Auger Diameter 20" 20" 20" 20" 20" 18"
    Unload Speed (bushels/min.) 600 600 600 550 550 500
    Flighting Thickness 7/16" 7/16" 7/16" 7/16" 7/16" 7/16"
    Hub Size/Spindle Diameter - 12-bolt/6" 10-bolt/4.5" 10-bolt/4.5" 10-bolt/4.5" 10-bolt/4.5"
    Hydraulic Remotes Required 4 4 4 4 4 4
    Front/Rear Slopes (degrees) 32/30 32/30 40/30 40/30 40/30 40/30
    Hopper Length 28' 28' 21' 6" 19' 5" 17' 11" 17' 11"
    Hopper Width 14' 12' 7" 13' 4" 11' 10" 11' 10" 11' 10"
    Auger Side Reach Max

    Measured to Inside Edge of Rubber Spout

    9' 6" 9' 6" 9' 6" 9' 1" 9' 1" 9' 9"
    Auger Side Reach Min 5' 9" 5' 9" 5' 10" 6' 8" 6' 8" 6' 9"
    Hitch to Spout when Straight Down (forward reach) 4' 5" 4' 5" 4' 2' 5" 2' 5" 3' 7"
    Overall Transport Length 30' 7" 30' 7" 26' 26' 4" 26' 4" 22' 11"
    Hitch to Center of Axle 18' 18' 15' 10" 15' 5" 15' 14' 8"
    Single Wheels and Tires
    Measured Undercarriage N/A IF 1250/50x32 Tire Adj. Axle 1250/50x32 Tire Adj. Axle 1050/50x32 Tire Rigid Axle 800/65x32 Rigid Axle 800/65x32
    Empty Weight (lbs) - 19,050 15,645 14,000 12,160 11,360
    Hitch Height - 1' 9" 1' 10" 1' 7" 1' 7" 1' 7"
    Hopper Height Low Side - 11' 8" 11' 11" 11' 8" 11' 2" 10' 4"
    Hopper Height High Side - 13' 1" 12' 11" 12' 8" 12' 2" 11' 3"
    Auger Height with Spout Straight Down - 13' 6" 13' 13' 1" 13' 1" 12' 5"
    Height to Top of Auger in Unload Position - 17' 11" 17' 4" 17' 3" 17' 3" 17' 1"
    Width Outside of Tires - 15' 3" 16' 2" 15' 7" 12' 9" 12' 9"
    Center of Tire to Center of Tire - 11' 1" 12' 1" 12' 2" 10' 1" 10' 1"
    Under Frame Height - 1' 4" 1' 8" 1' 5" 1' 5" 1' 3"
    Tracks
    Measured Undercarriage 42"x148" Equalizer Track 36"x148" Traditional Track 36"x131" Traditional Track 36"x112" Auto-Tension Track 36"x112" Auto-Tension Track N/A
    Empty Weight (lbs) 30,431 29,931 22,438 23,500 19,420 -
    Hitch Height 1' 9" 1' 9" 1' 4" 1' 7" 1' 5" -
    Hopper Height Low Side 11' 8" 11' 8" 11' 5" 11' 6" 11' -
    Hopper Height High Side 13' 3" 13' 1" 12' 5" 12' 6" 12' -
    Auger Height with Spout Straight Down 13' 6" 13' 6" 12' 6" 13' 1" 13' 1" -
    Height to Top of Auger in Unload Position 17' 11" 17' 11" 16' 10" 17' 3" 17' 3" -
    Width Outside of Tracks 13' 11" 13' 5" 12' 13' 11" 13' 11" -
    Center of Track to Center of Track 10' 5" 10' 5" 9' 10' 11" 10' 11" -
    Under Frame Height 1' 4" 1' 2" 1' 3" 1' 1" 1' 1" -

    Loaded Tire Ground Pressure - P.S.I. calculated at the 3" penetration level.
    For use as a comparative guide in choosing between various tire options

    Model V1500 V1300 V1100 V1000 V800 V700
    42"x148" Equalizer Tracks 12.14 10.84 - - - -
    42"x131" Equalizer Tracks - 12.78 10.99 - - -
    36"x148" Traditional Tracks 13.86 12.35 10.61 - - -
    36"x131" Traditional Tracks - - 12.53 11.55 - -
    36"x112" Auto-Tension Tracks - - 13.99 12.86 11.29 -
    480/80x46 R-1 Straddle Duals (158A8 LI) - - - 18.79 - -
    420/80x46 R-1 Straddle Duals (151A8 LI) - - - - 19.69 17.58
    520/85x42 R-1 Straddle Duals (157A8 LI) - - - 15.52 13.46 12.02
    480/80x42 R-1 Straddle Duals (151A8 LI) - - - - 16.77 14.96
    IF 1250/50x32 R-1W (201A8 LI) - 16.24 - - - -
    IF 1250/50x32 R-1W (188A8 LI) - - 13.74 12.59 - -
    1250/50x32 R-1W (188A8 LI) - - 15.97 14.62 - -
    LSW 1100/45x46 R-1 (195D LI) - - 14.76 - - -
    1050/50x32 R-1W (178A8 LI) - - 20.00 18.15 - -
    900/70x32 R-1W (188A8 LI) - - 22.44 - - -
    900/65x32 R-3 (193A8 LI) - - 23.02 21.02 18.16 16.17
    900/60x32 R-1W (181A8 LI) - - - 24.50 21.16 18.84
    800/65x32 R-1W (172A8 LI) - - - - 19.96 17.77
    IF 800/60x32 R-3 (181A8 LI) - - - - 23.97 21.33
    650/75x32 R-1W (172A8 LI) - - - - - 22.43
    520/85x38 R-1 (173A8 LI) - - - - - 31.66

    Literature
